Small body and strong performance
DTS6012M

The DTS6012M is a fully integrated single-channel dToF rangefinder mini-module with a self-developed, highly sensitive infrared-enhanced SPAD sensor with a 20m range. The on-chip integration of time-dependent photon thresholding algorithm, histogram statistical algorithm, and fast TDC architecture realizes high-precision ranging while achieving 12m@160KLux ambient light immunity with reflectance correction.

The DTS6012M integrated power module is powered by a single 3.3V supply with built-in temperature compensation. Supporting I2C and UART interfaces for easy integration and use, and featuring a compact and reliable optical LGA package with small size and light weight, it is an excellent choice for micro-small dToF applications.


Extremely Light Weight
Product weight only 1.35 grams.
Extremely Light Weight
Product weight only 1.35 grams.
Ultra-Compact Form Factor
Just 21x15x7.87 millimeters.
Ultra-Compact Form Factor
Just 21x15x7.87 millimeters.
Range Up to 20m
±6cm@<4m, ±1%@>4m, Maximum range of 20 meters.
Range Up to 20m
±6cm@<4m, ±1%@>4m, Maximum range of 20 meters.
Excellent Anti-Ambient Light Performance
Integrated Time-of-Flight photon threshold anti-ambient light algorithm,with capacity at12m@160KLux.
Excellent Anti-Ambient Light Performance
Integrated Time-of-Flight photon threshold anti-ambient light algorithm,with capacity at12m@160KLux.
Capture at 1kfps: Speed in Every Frame
Stable Output on Configured Cycles, Max Frame Rate at 1kfps.
Capture at 1kfps: Speed in Every Frame
Stable Output on Configured Cycles, Max Frame Rate at 1kfps.
Outputs Dual-Peak
Integrated histogram algorithm outputs dual-peak positions for easy calibration.
Outputs Dual-Peak
Integrated histogram algorithm outputs dual-peak positions for easy calibration.
Excellent Reflectance Correction Capabilities
Accurately measures surfaces with varying reflectance.
Excellent Reflectance Correction Capabilities
Accurately measures surfaces with varying reflectance.
